Infrared light source can be customized.
Operating voltage: 24-240VAC,12-240VDC, 10-30VDC
Output function: NPN/PNP,light-ON,dark-ON.
Protection level: IP67
With polarity, overload, short circuit protection.
Wiring method:lead wire type、connector type.
Operating temperature:-25℃...+55℃
With the advantages of small size, multi-function, long service life, high precision, fast response speed, long detection distance and strong anti-light, electric and magnetic interference ability.
Retro-reflective;Retro-reflective(with polarizing filter) can be customized.
| Diameter | Mounting | Operating distance/Sn | Housing material | Operating voltage | Output | model | Connection type | |
|---|---|---|---|---|---|---|---|---|
 |
M18*79 | Retro-reflective | 3m | PBT | 24-240VAC | AC 4 Wire | HLR2-P18 | M12 Connector |
 |
M18*67 | Retro-reflective | 3m | PBT | 24-240VAC | AC 4 Wire | HLR2-P18 | PVC, 2 m |
|
M18*79 | Retro-reflective(with polarizing filter) | 1m | PBT | 24-240VAC | AC 4 Wire | HLR-P18 | M12 Connector |
|
M18*67 | Retro-reflective(with polarizing filter) | 1m | PBT | 24-240VAC | AC 4 Wire | HLR-P18 | PVC, 2 m |
 |
M18*79 | Retro-reflective | 3m | Nickel plated brass | 24-240VAC | AC 4 Wire | HLR2-C18 | M12 Connector |
 |
M18*67 | Retro-reflective | 3m | Nickel plated brass | 24-240VAC | AC 4 Wire | HLR2-C18 | PVC, 2 m |
|
M18*79 | Retro-reflective(with polarizing filter) | 1m | Nickel plated brass | 24-240VAC | AC 4 Wire | HLR-C18 | M12 Connector |
|
M18*67 | Retro-reflective(with polarizing filter) | 1m | Nickel plated brass | 24-240VAC | AC 4 Wire | HLR-C18 | PVC, 2 m |
|
M18*79 | Retro-reflective | 3m | PBT | 10-30VDC | DC 4 Wire | HLR2-P18 | M12 Connector |
|
M18*67 | Retro-reflective | 3m | PBT | 10-30VDC | DC 4 Wire | HLR2-P18 | PVC, 2 m |
|
M18*79 | Retro-reflective(with polarizing filter) | 1m | PBT | 10-30VDC | DC 4 Wire | HLR-P18 | M12 Connector |
|
M18*67 | Retro-reflective(with polarizing filter) | 1m | PBT | 10-30VDC | DC 4 Wire | HLR-P18 | PVC, 2 m |
|
M18*79 | Retro-reflective | 3m | Nickel plated brass | 10-30VDC | DC 4 Wire | HLR2-C18 | M12 Connector |
|
M18*67 | Retro-reflective | 3m | Nickel plated brass | 10-30VDC | DC 4 Wire | HLR2-C18 | PVC, 2 m |
|
M18*79 | Retro-reflective(with polarizing filter) | 1m | Nickel plated brass | 10-30VDC | DC 4 Wire | HLR-C18 | M12 Connector |
|
M18*67 | Retro-reflective(with polarizing filter) | 1m | Nickel plated brass | 10-30VDC | DC 4 Wire | HLR-C18 | PVC, 2 m |
 |
M12*76.5 | Retro-reflective | 1.5m | PBT | 10-30VDC | DC 4 Wire | HLR2-P12 | M12 Connector |
 |
M12*67 | Retro-reflective | 1.5m | PBT | 10-30VDC | DC 4 Wire | HLR2-P12 | PVC, 2 m |
|
M12*76.5 | Retro-reflective(with polarizing filter) | 500.0mm | PBT | 10-30VDC | DC 4 Wire | HLR-P12 | M12 Connector |
|
M12*67 | Retro-reflective(with polarizing filter) | 500.0mm | PBT | 10-30VDC | DC 4 Wire | HLR-P12 | PVC, 2 m |
 |
M12*76.5 | Retro-reflective | 1.5m | Nickel plated brass | 10-30VDC | DC 4 Wire | HLR2-C12 | M12 Connector |
 |
M12*67 | Retro-reflective | 1.5m | Nickel plated brass | 10-30VDC | DC 4 Wire | HLR2-C12 | PVC, 2 m |
|
M12*76.5 | Retro-reflective(with polarizing filter) | 500.0mm | Nickel plated brass | 10-30VDC | DC 4 Wire | HLR-C12 | M12 Connector |
|
M12*67 | Retro-reflective(with polarizing filter) | 500.0mm | Nickel plated brass | 10-30VDC | DC 4 Wire | HLR-C12 | PVC, 2 m |
