Infrared light source can be customized.
Operating voltage: 24-240VAC,12-240VDC, 10-30VDC
Output function: NPN/PNP,light-ON,dark-ON.
Protection level: IP67
With polarity, overload, short circuit protection.
Wiring method:lead wire type、connector type.
Operating temperature:-25℃...+55℃
P5050 series with transistor output and relay output.
With the advantages of small size, multi-function, long service life, high precision, fast response speed, long detection distance and strong anti-light, electric and magnetic interference ability.

Diameter	Mounting	Operating distance/Sn	Housing material	Operating voltage	Output	model	Connection type
M18*79	Diffuse	500.0mm	PBT	24-240VAC	AC 4 Wire	HLD2-P18	M12 Connector
M18*67	Diffuse	500.0mm	PBT	24-240VAC	AC 4 Wire	HLD2-P18	PVC, 2 m
M18*79	Diffuse	150.0mm	PBT	24-240VAC	AC 4 Wire	HLD-P18	M12 Connector
M18*67	Diffuse	150.0mm	PBT	24-240VAC	AC 4 Wire	HLD-P18	PVC, 2 m
M18*79	Diffuse	500.0mm	Nickel plated brass	24-240VAC	AC 4 Wire	HLD2-C18	M12 Connector
M18*67	Diffuse	500.0mm	Nickel plated brass	24-240VAC	AC 4 Wire	HLD2-C18	PVC, 2 m
M18*79	Diffuse	150.0mm	Nickel plated brass	24-240VAC	AC 4 Wire	HLD-C18	M12 Connector
M18*67	Diffuse	150.0mm	Nickel plated brass	24-240VAC	AC 4 Wire	HLD-C18	PVC, 2 m
M18*79	Diffuse	500.0mm	PBT	10-30VDC	DC 4 Wire	HLD2-P18	M12 Connector
M18*67	Diffuse	500.0mm	PBT	10-30VDC	DC 4 Wire	HLD2-P18	PVC, 2 m
M18*79	Diffuse	150.0mm	PBT	10-30VDC	DC 4 Wire	HLD-P18	M12 Connector
M18*67	Diffuse	150.0mm	PBT	10-30VDC	DC 4 Wire	HLD-P18	PVC, 2 m
M18*79	Diffuse	500.0mm	Nickel plated brass	10-30VDC	DC 4 Wire	HLD2-C18	M12 Connector
M18*67	Diffuse	500.0mm	Nickel plated brass	10-30VDC	DC 4 Wire	HLD2-C18	PVC, 2 m
M18*79	Diffuse	150.0mm	Nickel plated brass	10-30VDC	DC 4 Wire	HLD-C18	M12 Connector
M18*67	Diffuse	150.0mm	Nickel plated brass	10-30VDC	DC 4 Wire	HLD-C18	PVC, 2 m
M12*76.5	Diffuse	200.0mm	PBT	10-30VDC	DC 4 Wire	HLD-P12	M12 Connector
M12*67	Diffuse	200.0mm	PBT	10-30VDC	DC 4 Wire	HLD-P12	PVC, 2 m
M12*76.5	Diffuse	200.0mm	Nickel plated brass	10-30VDC	DC 4 Wire	HLD-C12	M12 Connector
M12*67	Diffuse	200.0mm	Nickel plated brass	10-30VDC	DC 4 Wire	HLD-C12	PVC, 2 m
