Current position：Home - Products - Ordinary inductive sensors - DC two-wire inductive proximity switch

Operating voltage: 10-60VDC Output function:
NPN/PNP, NO/NC optional
Polarity, overload, short circuit protection
Protection class: IP67
Straight Out, Insertion
Operating temperature-25℃-+70℃
Optimized traditional process and advanced packaging technology to ensure long-term stable operation in harsh environments
Data download

Diameter	Mounting	Operating distance/Sn	Housing material	Operating voltage	Output	Model	Connection type
M8	flush/non-flush	1.5mm/2mm//4mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	M8*1	straight line
M8	flush/non-flush	1.5mm/2mm/4mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	M8*1	straight line
M12	flush/non-flush	2mm/4mm/8mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	M12*1	connector
M12	flush/non-flush	2mm/4mm/8mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	M12*1	connector
M12	flush/non-flush	2mm/4mm/8mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	M12*1	straight line
M12	flush/non-flush	2mm/4mm/8mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	M12*1	straight line
M18	flush/non-flush	5mm/8mm/16mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	M18*1	straight line
M18	flush/non-flush	5mm/8mm/16mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	M18*1	straight line
M18	flush/non-flush	5mm/8mm/16mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	M18*1	connector
M18	flush/non-flush	5mm/8mm/16mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	M18*1	connector
M30	flush/non-flush	10mm/15mm/30mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	M30*1	straight line
M30	flush/non-flush	10mm/15mm/30mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	M30*1	straight line
M30	flush/non-flush	10mm/15mm/30mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	M30*1	connector
M30	flush/non-flush	10mm/15mm/30mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	M30*1	connector
RS40	flush/non-flush	15mm/30mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	RS40*40	connector
R40	flush/non-flush	15mm/30mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	R40*40	connector
R40	flush/non-flush	15mm/30mm	Nickel plated copper/stainless steel	10-60VDC	DC 2 Line	R40*40	connector
